Drive Units 2 x 176 mm Purify Audio bass/mid range unit, 1 x Low mass Viawave Ribbon precision tweeter 32 Hz to 45 KHz +/- 2 dB on axis
Frequency Response 4 Ω nominal, 3 Ω minimum
Impedance 89 dB spl at 1 metre on axis. 2.83 V input
Sensitivity 2nd order bass , 2nd order tweeter with Jantzen
Crossover Alumin Z-cap
Power Handling 150 W peak un-clipped programme
Dimensions Height – Standmount – 44.5 cm Floor standing – 119 cm Width – Standmount and Floor standing – 23 cm Depth – Standmount – 37 cm Floor standing – 40 cm
Net Weight 11Kg – Standmount 32 Kg – Floorstanding
Finishes Standard finish available in black hide and oak
Bespoke options available in various hides and
hardwood. Jantzen Alumin Z caps and Mundorf
resistors as standard.
